Netdata 是一個免費、開源、實時的服務器監控工具,可以可視化和監控實時數據,如 CPU 使用率、RAM 使用率、負載、SWAP 使用率、帶寬使用率、磁盤使用率等。它可以幫助系統管理員了解您的系統或應用程序中正在發生的事情以及剛剛發生的事情。它可以安裝在任何物理服務器、虛擬機、容器和物聯網設備上。它提供了一個交互式 Web 界面來查看您的服務器指標,并支持用于持久存儲的各種數據存儲。
在本教程中,我們將向您展示如何在 Alma linux 8 上安裝 Netdata 監控工具。
先決條件
- 運行 Alma Linux 8 的服務器。
- 使用您的服務器 IP 指向的有效域名。
- 在服務器上配置了 root 密碼。
安裝所需的依賴項
首先,您需要安裝 EPEL 存儲庫和安裝 Netdata 所需的其他依賴項,您可以通過運行以下命令來安裝所有這些:
dnf install epel-release -y
dnf install git libuuid-devel autoconf automake pkgconfig zlib-devel curl findutils libmnl gcc make -y
安裝完所有軟件包后,您可以繼續下一步。
安裝網絡數據
默認情況下,Netdata 不包含在 Alma Linux 默認存儲庫中。因此,您需要從源代碼安裝它。
首先,使用以下命令從 Git 存儲庫下載最新版本的 Netdata:
git clone --recurse-submodules https://github.com/netdata/netdata.git --depth=100
下載完成后,將目錄更改為 netdata 并使用以下命令安裝所有必需的依賴項:
cd
netdata ./packaging/installer/install-required-packages.sh --non-interactive --dont-wait netdata
接下來,使用以下命令安裝其他軟件包:
dnf --enablerepo=powertools install libuv-devel
接下來,運行 Netdata 安裝腳本開始安裝。
./netdata-installer.sh
您將獲得以下輸出:
--- real-time performance monitoring, done right! ---
You are about to build and install netdata to your system.
The build process will use /tmp for
any temporary files. You can override this by setting $TMPDIR to a
writable directory where you can execute files.
It will be installed at these locations:
- the daemon at /usr/sbin/netdata
- config files in /etc/netdata
- web files in /usr/share/netdata
- plugins in /usr/libexec/netdata
- cache files in /var/cache/netdata
- db files in /var/lib/netdata
- log files in /var/log/netdata
- pid file at /var/run/netdata.pid
- logrotate file at /etc/logrotate.d/netdata
This installer allows you to change the installation path.
Press Control-C and run the same command with --help for help.
NOTE:
Anonymous usage stats will be collected and sent to Netdata.
To opt-out, pass --disable-telemetry option to the installer or export
the environment variable DISABLE_TELEMETRY to a non-zero or non-empty value
(e.g: export DISABLE_TELEMETRY=1).
Press ENTER to build and install netdata to your system >
按 Enter 鍵將 Netdata 安裝到您的系統。安裝 Netdata 后,您將獲得以下輸出:
將 netdata.tarball.checksum 設置為“new_installation”
Setting netdata.tarball.checksum to 'new_installation'
--- We are done! ---
^
|.-. .-. .-. .-. .-. . netdata .-. .-. .-. .-. .-. .-
| '-' '-' '-' '-' '-' '-' '-' '-' '-' '-'
+----+-----+-----+-----+-----+-----+-----+-----+-----+-----+-----+-----+--->
--- is installed and running now! ---
enjoy real-time performance and health monitoring...
systemctl start netdata
systemctl enable netdata
您現在可以使用以下命令檢查 Netdata 的狀態。
systemctl status netdata
您將獲得以下輸出:
? netdata.service - Real time performance monitoring
Loaded: loaded (/usr/lib/systemd/system/netdata.service; enabled; vendor preset: disabled)
Active: active (running) since Sat 2022-03-19 04:22:22 UTC; 4min 16s ago
Main PID: 58935 (netdata)
Tasks: 50 (limit: 11412)
Memory: 103.1M
CGroup: /system.slice/netdata.service
??58935 /usr/sbin/netdata -P /var/run/netdata/netdata.pid -D
??58938 /usr/sbin/netdata --special-spawn-server
??59063 /usr/libexec/netdata/plugins.d/Apps.plugin 1
??59064 /usr/libexec/netdata/plugins.d/ebpf.plugin 1
??59065 /usr/libexec/netdata/plugins.d/go.d.plugin 1
Mar 19 04:22:22 linux systemd[1]: Starting Real time performance monitoring...
Mar 19 04:22:22 linux systemd[1]: Started Real time performance monitoring.
Mar 19 04:22:22 linux netdata[58935]: CONFIG: cannot load cloud config '/var/lib/netdata/cloud.d/cloud.conf'. Running with internal defaults.
Mar 19 04:22:22 linux netdata[58935]: 2022-03-19 04:22:22: netdata INFO : MAIN : CONFIG: cannot load cloud config '/var/lib/netdata/cloud.d/>
Mar 19 04:22:22 linux netdata[58935]: 2022-03-19 04:22:22: netdata INFO : MAIN : Found 0 legacy dbengines, setting multidb diskspace to 256MB
Mar 19 04:22:22 linux netdata[58935]: 2022-03-19 04:22:22: netdata INFO : MAIN : Created file '/var/lib/netdata/dbengine_multihost_size' to >
Mar 19 04:22:22 linux netdata[58935]: Found 0 legacy dbengines, setting multidb diskspace to 256MB
Mar 19 04:22:22 linux netdata[58935]: Created file '/var/lib/netdata/dbengine_multihost_size' to store the computed value
Mar 19 04:22:23 linux ebpf.plugin[59064]: Does not have a configuration file inside `/etc/netdata/ebpf.d.conf. It will try to load stock file.
Mar 19 04:22:23 linux ebpf.plugin[59064]: Cannot read process groups configuration file '/etc/netdata/apps_groups.conf'. Will try '/usr/lib/n>
此時,Netdata 正在運行并監聽 19999 端口。您可以使用以下命令檢查它:
ss -antpl | grep netdata
您將獲得以下輸出:
LISTEN 0 128 127.0.0.1:8125 0.0.0.0:* users:(("netdata",pid=58935,fd=29))
LISTEN 0 128 0.0.0.0:19999 0.0.0.0:* users:(("netdata",pid=58935,fd=6))
LISTEN 0 128 [::1]:8125 [::]:* users:(("netdata",pid=58935,fd=28))
LISTEN 0 128 [::]:19999 [::]:* users:(("netdata",pid=58935,fd=7))
完成后,您可以繼續下一步。
配置防火墻
如果您在系統上使用 firewalld 防火墻,那么您需要允許端口19999和80通過 firewalld。您可以使用以下命令允許它們:
firewall-cmd --permanent --add-port=19999/tcp
firewall-cmd --permanent --add-port=80/tcp
接下來,重新加載 firewalld 守護進程以應用更改:
firewall-cmd --reload
完成后,您可以繼續下一步。
將 Nginx 配置為 Netdata 的反向代理
將 Nginx 安裝和配置為反向代理以訪問 Netdata 始終是一個好主意。首先,使用以下命令安裝 Nginx 服務器:
dnf install nginx httpd-tools -y
接下來,使用以下命令生成密碼文件:
htpasswd -c /etc/nginx/.htpasswd netadmin
設置您的管理員密碼,如下所示:
New password:
Re-type new password:
Adding password for user netadmin
接下來,使用以下命令創建一個 Nginx 虛擬主機配置文件:
nano /etc/nginx/conf.d/netdata.conf
添加以下行:
upstream backend {
server 127.0.0.1:19999;
keepalive 64;
}
server {
listen 80;
server_name netdata.example.com;
location / {
proxy_set_header X-Forwarded-Host $host;
proxy_set_header X-Forwarded-Server $host;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_pass http://backend;
proxy_http_version 1.1;
proxy_pass_request_headers on;
proxy_set_header Connection "keep-alive";
proxy_store off;
auth_basic "Private Property";
auth_basic_user_file /etc/nginx/.htpasswd;
}
}
保存并關閉文件,然后驗證 Nginx 是否存在任何語法配置錯誤:
nginx -t
如果一切正常,您將獲得以下輸出:
nginx: the configuration file /etc/nginx/nginx.conf syntax is ok
nginx: configuration file /etc/nginx/nginx.conf test is successful
接下來,重新啟動 Nginx 服務以應用配置更改:
systemctl restart nginx
您還可以使用以下命令檢查 Nginx 狀態:
systemctl status nginx
您應該看到以下輸出:
? nginx.service - The nginx HTTP and reverse proxy server
Loaded: loaded (/usr/lib/systemd/system/nginx.service; disabled; vendor preset: disabled)
Active: active (running) since Sat 2022-03-19 04:28:44 UTC; 4s ago
Process: 61706 ExecStart=/usr/sbin/nginx (code=exited, status=0/SUCCESS)
Process: 61705 ExecStartPre=/usr/sbin/nginx -t (code=exited, status=0/SUCCESS)
Process: 61703 ExecStartPre=/usr/bin/rm -f /run/nginx.pid (code=exited, status=0/SUCCESS)
Main PID: 61708 (nginx)
Tasks: 2 (limit: 11412)
Memory: 3.7M
CGroup: /system.slice/nginx.service
??61708 nginx: master process /usr/sbin/nginx
??61709 nginx: worker process
Mar 19 04:28:44 linux systemd[1]: Starting The nginx HTTP and reverse proxy server...
Mar 19 04:28:44 linux nginx[61705]: nginx: the configuration file /etc/nginx/nginx.conf syntax is ok
Mar 19 04:28:44 linux nginx[61705]: nginx: configuration file /etc/nginx/nginx.conf test is successful
Mar 19 04:28:44 linux systemd[1]: nginx.service: Failed to parse PID from file /run/nginx.pid: Invalid argument
Mar 19 04:28:44 linux systemd[1]: Started The nginx HTTP and reverse proxy server.
完成后,您可以繼續下一步。
訪問網絡數據儀表板
現在,打開您的 Web 瀏覽器并使用 URL http://your-server-ip 訪問 Netdata 儀表板。您應該看到 Netdata 登錄頁面:
提供您的管理員用戶名、密碼,然后單擊登錄按鈕。您應該在以下頁面上看到 Netdata 儀表板:
結論
恭喜!您已在 Alma Linux 8 上成功安裝了 Netdata 監控工具。您現在可以從 Netdata 儀表板開始實時監控您的服務器矩陣,如果您有任何問題,請隨時問我。
